PD 407824

Catalog No. T16446 CAS 622864-54-4

Synonyms: PD-407824

PD 407824 is a chemical BMP sensitiser that promotes increased cellular sensitivity to subthreshold amounts of BMP4.PD 407824 is a potent inhibitor of the checkpoint kinases Chk1 and WEE1 (IC50s: 47 and 97 nM, respectively).

All products from TargetMol are for Research Use Only. Not for Human or Veterinary or Therapeutic Use.

PD 407824, CAS 622864-54-4

Please contact us for prices and availability for the specification of product you are interested at.
Product consultation

Select Batch

Purity: 98.02%

Biological Description

Chemical Properties

Storage & Solubility Information

Description	PD 407824 is a chemical BMP sensitiser that promotes increased cellular sensitivity to subthreshold amounts of BMP4.PD 407824 is a potent inhibitor of the checkpoint kinases Chk1 and WEE1 (IC50s: 47 and 97 nM, respectively).
Targets&IC50	Chk1:47 nM, WEE1:97 nM
In vitro	Inhibiting Wee1 and Chk1 kinases can lead to the disappearance of DNA damage-induced G2 checkpoint. Research findings indicate that PD 407824 selectively acts on CHK1 and WEE1, with IC50 values exceeding 3.4µM and 3.75µM for PKC and Cdk4, respectively[3].

Synonyms	PD-407824
Molecular Weight	328.32
Formula	C20H12N2O3
CAS No.	622864-54-4

Storage

store at low temperature

Powder: -20°C for 3 years | In solvent: -80°C for 1 year

Solubility Information

DMSO: 100 mg/mL (304.88 mM), Sonication is recommended.

References and Literature

1. Palmer BD, et al. 4-Phenylpyrrolo[3,4-c]carbazole-1,3(2H,6H)-dione inhibitors of the checkpoint kinase WeeStructure-activity relationships for chromophore modification and phenyl ring substitution. J Med Chem. 2006 Aug 10;49(16):4896-911. 2. Feng L, et al. Discovery of a Small-Molecule BMP Sensitizer for Human Embryonic Stem Cell Differentiation. Cell Rep. 2016 May 31;15(9):2063-75. 3. Smaill JB,et al. Synthesis and structure-activity relationships of N-6 substituted analogues of 9-hydroxy-4-phenylpyrrolo[3,4-c]carbazole-1,3(2H,6H)-diones as inhibitors of Wee1 and Chk1 checkpoint kinases. Eur J Med Chem. 2008 Jun;43(6):1276-96.

Related Products

Related compounds with same targets

ZNL 02-096 ZN-c3 WEE1-IN-3 RP-6306 Adavosertib GSK-1520489A Debio-0123 PD0166285

Dose Conversion

You can also refer to dose conversion for different animals. More

In vivo Formulation Calculator (Clear solution)

Step One: Enter information below

Dosage

mg/kg

Average weight of animals

Dosing volume per animal

Number of animals

Step Two: Enter the in vivo formulation

% DMSO+

% +

% Tween 80+

% ddH₂O

%DMSO+

Calculate Reset

Calculation results:

Working concentration: mg/ml;

Method for preparing DMSO master liquid: mg drug pre-dissolved in μL DMSO (Master liquid concentration mg/mL)，Please contact us first if the concentration exceeds the DMSO solubility of the batch of drug.

Method for preparing in vivo formulation：Take μL DMSO master liquid, next add μL PEG300， mix and clarify, next add μL Tween 80，mix and clarify, next add μL ddH₂O, mix and clarify.

Note:

Be sure to add the solvent(s) in order. Physical methods such as vortex, ultrasound or hot water bath can be used to aid dissolving.

Calculator

Molarity Calculator

Dilution Calculator

Reconstitution Calculation

Molecular Weight Calculator

Mass

Concentration

Volume

Molecular Weight

Molarity Calculator allows you to calculate the

Mass of a compound required to prepare a solution of known volume and concentration
Volume of solution required to dissolve a compound of known mass to a desired concentration
Concentration of a solution resulting from a known mass of compound in a specific volume

See Example

An example of a molarity calculation using the molarity calculator
What is the mass of compound required to make a 10 mM stock solution in 10 ml of water given that the molecular weight of the compound is 197.13 g/mol?
Enter 197.13 into the Molecular Weight (MW) box
Enter 10 into the Concentration box and select the correct unit (millimolar)
Enter 10 into the Volume box and select the correct unit (milliliter)
Press calculate
The answer of 19.713 mg appears in the Mass box

Concentration (Start)

Volume (Start)

Concentration (End)

Volume (End)

Calculator the dilution required to prepare a stock solution

Calculate the dilution required to prepare a stock solution
The dilution calculator is a useful tool which allows you to calculate how to dilute a stock solution of known concentration. Enter C1, C2 & V2 to calculate V1.

See Example

An example of a dilution calculation using the Tocris dilution calculator
What volume of a given 10 mM stock solution is required to make 20ml of a 50 μM solution?
Using the equation C1V1 = C2V2, where C1=10 mM, C2=50 μM, V2=20 ml and V1 is the unknown:
Enter 10 into the Concentration (start) box and select the correct unit (millimolar)
Enter 50 into the Concentration (final) box and select the correct unit (micromolar)
Enter 20 into the Volume (final) box and select the correct unit (milliliter)
Press calculate
The answer of 100 microliter (0.1 ml) appears in the Volume (start) box

Volume (to add to vial)

Mass (in vial)

Desired Reconstitution Concentration

Calculate the volume of solvent required to reconstitute your vial.

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial.
Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

Molecule Formula

Molecular Weight g/mol

Enter the chemical formula of a compound to calculate its molar mass and elemental composition

Tip: Chemical formula is case sensitive: C10H16N2O2 c10h16n2o2

Instructions to calculate molar mass (molecular weight) of a chemical compound:
To calculate molar mass of a chemical compound, please enter its chemical formula and click 'Calculate'.
Definitions of molecular mass, molecular weight, molar mass and molar weight:
Molecular mass (molecular weight) is the mass of one molecule of a substance and is expressed n the unified atomic mass units (u). (1 u is equal to 1/12 the mass of one atom of carbon-12)
Molar mass (molar weight) is the mass of one mole of a substance and is expressed in g/mol.
