Crisaborole

Catalog No. T4285 CAS 906673-24-3

Synonyms: AN-2728, PF-06930164

Crisaborole (AN-2728) is a Phosphodiesterase 4 Inhibitor.

All products from TargetMol are for Research Use Only. Not for Human or Veterinary or Therapeutic Use.

Crisaborole, CAS 906673-24-3

Pack Size	Availability	Price/USD
10 mg	In stock	$ 38.00
50 mg	In stock	$ 50.00
100 mg	In stock	$ 83.00
200 mg	In stock	$ 111.00
1 mL * 10 mM (in DMSO)	In stock	$ 46.00

Bulk Inquiry

Select Batch

Purity: 99.91%

Biological Description

Chemical Properties

Storage & Solubility Information

Description	Crisaborole (AN-2728) is a Phosphodiesterase 4 Inhibitor.
Targets&IC50	PDE4:0.49 μM
In vitro	AN-2728 inhibits PDE isozymes PDE1A3, PDE3Cat , PDE4Cat and PDE7A1 with IC50 values of 6.1, 6.4, 0.11 and 0.73 μM. AN-2728 inhibits PDE4, TNF-α, IL-2, IFN-γ, IL-5 and IL-10 with IC50 values of 0.49, 0.54, 0.61, 0.83, 2.4 and 5.3 μM. AN-2728 shows the most potent activity against PDE4 catalytic domain, but it also shows inhibition against PDE1A3, PDE3Cat, and PDE7A1. Crystallography reveals that interaction of benzoxaboroles with the hydrophobic pocket in the PDE4 catalytic domain increase their affinity for PDE4. These benzoxaboroles strongly suppresses the secretion of cytokines associated with Ps and AD.
In vivo	AN-2728 is well tolerated and significantly impacts efficacy markers, showing comparable results to positive controls in clinical trials. It effectively inhibits ear edema induced by phorbol ester with a dosing of 1 mg/ear×2 (78% and 68%, respectively), mirroring the efficacy of dexamethasone. This suggests AN-2728 possesses notable anti-inflammatory properties and skin penetration capabilities.

Synonyms	AN-2728, PF-06930164
Molecular Weight	251.05
Formula	C14H10BNO3
CAS No.	906673-24-3

Storage

Powder: -20°C for 3 years | In solvent: -80°C for 1 year

Solubility Information

DMSO: 32 mg/mL

References and Literature

1. Akama T, et al. Discovery and structure-activity study of a novel benzoxaborole anti-inflammatory agent (AN2728) for the potential topical treatment of psoriasis and atopic dermatitis. Bioorg Med Chem Lett. 2009 Apr 15;19(8):2129-32. 2. Nazarian R, et al. AN-2728, a PDE4 inhibitor for the potential topical treatment of psoriasis and atopic dermatitis. Curr Opin Investig Drugs. 2009 Nov;10(11):1236-42.

Related compound libraries

This product is contained In the following compound libraries：

Inhibitor Library Drug Repurposing Compound Library EMA Approved Drug Library Anti-Neurodegenerative Disease Compound Library FDA-Approved & Pharmacopeia Drug Library Anti-Cardiovascular Disease Compound Library Drug-Fragment Library Bioactive Lipid Compound Library Clinical Compound Library Bioactive Compound Library

Related Products

Related compounds with same targets

uk-50001 Pentoxifylline Vardenafil dihydrochloride Ziritaxestat PDE7-IN-2 Dipyridamole Milrinone T-0156

Dose Conversion

You can also refer to dose conversion for different animals. More

In vivo Formulation Calculator (Clear solution)

Step One: Enter information below

Dosage

mg/kg

Average weight of animals

Dosing volume per animal

Number of animals

Step Two: Enter the in vivo formulation

% DMSO+

% +

% Tween 80+

% ddH₂O

%DMSO+

Calculate Reset

Calculation results:

Working concentration: mg/ml;

Method for preparing DMSO master liquid: mg drug pre-dissolved in μL DMSO (Master liquid concentration mg/mL)，Please contact us first if the concentration exceeds the DMSO solubility of the batch of drug.

Method for preparing in vivo formulation：Take μL DMSO master liquid, next add μL PEG300， mix and clarify, next add μL Tween 80，mix and clarify, next add μL ddH₂O, mix and clarify.

Note:

Be sure to add the solvent(s) in order. Physical methods such as vortex, ultrasound or hot water bath can be used to aid dissolving.

Calculator

Molarity Calculator

Dilution Calculator

Reconstitution Calculation

Molecular Weight Calculator

Mass

Concentration

Volume

Molecular Weight

Molarity Calculator allows you to calculate the

Mass of a compound required to prepare a solution of known volume and concentration
Volume of solution required to dissolve a compound of known mass to a desired concentration
Concentration of a solution resulting from a known mass of compound in a specific volume

See Example

An example of a molarity calculation using the molarity calculator
What is the mass of compound required to make a 10 mM stock solution in 10 ml of water given that the molecular weight of the compound is 197.13 g/mol?
Enter 197.13 into the Molecular Weight (MW) box
Enter 10 into the Concentration box and select the correct unit (millimolar)
Enter 10 into the Volume box and select the correct unit (milliliter)
Press calculate
The answer of 19.713 mg appears in the Mass box

Concentration (Start)

Volume (Start)

Concentration (End)

Volume (End)

Calculator the dilution required to prepare a stock solution

Calculate the dilution required to prepare a stock solution
The dilution calculator is a useful tool which allows you to calculate how to dilute a stock solution of known concentration. Enter C1, C2 & V2 to calculate V1.

See Example

An example of a dilution calculation using the Tocris dilution calculator
What volume of a given 10 mM stock solution is required to make 20ml of a 50 μM solution?
Using the equation C1V1 = C2V2, where C1=10 mM, C2=50 μM, V2=20 ml and V1 is the unknown:
Enter 10 into the Concentration (start) box and select the correct unit (millimolar)
Enter 50 into the Concentration (final) box and select the correct unit (micromolar)
Enter 20 into the Volume (final) box and select the correct unit (milliliter)
Press calculate
The answer of 100 microliter (0.1 ml) appears in the Volume (start) box

Volume (to add to vial)

Mass (in vial)

Desired Reconstitution Concentration

Calculate the volume of solvent required to reconstitute your vial.

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial.
Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

Molecule Formula

Molecular Weight g/mol

Enter the chemical formula of a compound to calculate its molar mass and elemental composition

Tip: Chemical formula is case sensitive: C10H16N2O2 c10h16n2o2

Instructions to calculate molar mass (molecular weight) of a chemical compound:
To calculate molar mass of a chemical compound, please enter its chemical formula and click 'Calculate'.
Definitions of molecular mass, molecular weight, molar mass and molar weight:
Molecular mass (molecular weight) is the mass of one molecule of a substance and is expressed n the unified atomic mass units (u). (1 u is equal to 1/12 the mass of one atom of carbon-12)
Molar mass (molar weight) is the mass of one mole of a substance and is expressed in g/mol.

bottom

Tech Support

Please see Inhibitor Handling Instructions for more frequently ask questions. Topics include: how to prepare stock solutions, how to store products, and cautions on cell-based assays & animal experiments, etc.
