AZ191

Catalog No. T6257 CAS 1594092-37-1

AZ191（IC50 of 17 nM） is an effective and specific DYRK1B inhibitor. The specificity of AZ191 for DYRK1B is about 5- and 110-fold greater over DYRK1A and DYRK2, respectively.

All products from TargetMol are for Research Use Only. Not for Human or Veterinary or Therapeutic Use.

AZ191, CAS 1594092-37-1

Pack Size	Availability	Price/USD
2 mg	In stock	$ 39.00
5 mg	In stock	$ 63.00
10 mg	In stock	$ 90.00
25 mg	In stock	$ 169.00
50 mg	In stock	$ 270.00
1 mL * 10 mM (in DMSO)	In stock	$ 68.00

Bulk Inquiry

Select Batch

Purity: 99.65%

Purity: 99.13%

Purity: 98.04%

Biological Description

Chemical Properties

Storage & Solubility Information

Description	AZ191（IC50 of 17 nM） is an effective and specific DYRK1B inhibitor. The specificity of AZ191 for DYRK1B is about 5- and 110-fold greater over DYRK1A and DYRK2, respectively.
Targets&IC50	DYRK1B:17 nM
In vitro	AZ191 selectively inhibits DYRK1B serine/threonine kinase activity with no effect on tyrosine kinase autophosphorylation. In HEK-293 cells, AZ191 also displays much greater potency for DYRK1B over DYRK1A, inhibiting CCND1 phosphorylation. In HD1B cells, AZ191 strongly inhibits the levels of the cell-cycle regulators, p21Cip1 and p27Kip1, and increases cell-cycle progression. [1]
Kinase Assay	Biochemical Binding Affinity – HTRF Assay: The p53-MDM2 HTRF assay is performed in buffer containing 50 mM Tris-HCl, pH 7.4, 100 mM NaCl, 1 mM DTT, 0.02 or 0.2 mg/ml BSA. Small-molecule inhibitors are stored in aliquots as 10 mM stock solutions in DMSO at 4°C in 96-deep-well plates. It is thawed and mixed immediately prior to testing. The compound is incubated with GST-MDM2 and a biotinylated p53 peptide for one hour at 37°C. Phycolink goat anti-GST (Type 1) allophycocyanin and Eu-8044-streptavidin are then added and followed by one hour incubation at room temperature. Plates are read using the Envision fluorescence reader. IC50 values are determined from inter-plate duplicate or triplicate sets of data. Data are analyzed by XLfit4 (Microsoft) using a 4 Parameter Logistic Model (Sigmoidal Dose-Response Model) and the equation Y= (A+ ((B-A)/ (1+ ((C/x)^D)))), where A and B are enzyme activity in the absence or presence of infinite inhibitor compound, respectively, C is the IC50 and D is the Hill coefficient.

Molecular Weight	429.52
Formula	C24H27N7O
CAS No.	1594092-37-1

Storage

Powder: -20°C for 3 years | In solvent: -80°C for 1 year

Solubility Information

H2O: < 1 mg/mL (insoluble or slightly soluble)

Ethanol: 1 mg/mL (2.32 mM)

DMSO: 79 mg/mL (183.9 mM)

References and Literature

1. Ashford AL, et al. Biochem J. 2014, 457(1), 43-56.

Citations

1. Wang C, Hu R, Wang T, et al.A bivalent β-carboline derivative inhibits macropinocytosis-dependent entry of pseudorabies virus by targeting the kinase DYRK1A.Journal of Biological Chemistry.2023: 104605.

Related compound libraries

This product is contained In the following compound libraries：

Tyrosine Kinase Inhibitor Library Inhibitor Library Target-Focused Phenotypic Screening Library Anti-Cancer Compound Library Bioactive Compound Library Bioactive Compounds Library Max Cell Cycle Compound Library NO PAINS Compound Library Kinase Inhibitor Library
